EMU Infos
dumper MetalliC, Tormod, zozo
date 17/10/2022
emulator
dev
PCB Infos
name 1760
description Alien Front (prototype)
year 2000.10.04 – 21:33:46
manufacturer WOW Entertainment - Sega

Technical references

CPUs

QTY Type clock position function
1x oscillator 28.000 osc1

ROMs

QTY Type position status
1x M27322 no_label.ic22 dumped
21x DA28F640J5 ic1s - ic21s dumped
1x X76F100 ic37 dumped

RAMs

QTY Type position
2x IDT71256 ic44,ic45

PLDs

QTY Type position status
1x EPM7064 315-6206 ic41 read protected

Others

Notes

It's a NAOMI cart.
Cart type: 171-7885A
Cart N°: no cart
Protection IC: SEGA 315-5881 (no number)
Key: no key

Files

1760
