Colt (bootleg of N.Y. Captor)

EMU Infos

dumper	Guru
date	11/11/2004
emulator	MAME 0.92
dev	Tomasz Slanina

PCB Infos

name	colt on Arcade Database
description	Colt (bootleg of N.Y. Captor)
year	1986
manufacturer

Technical references

CPUs

QTY	Type	clock	position	function
1x	Z80	4.000 MHz		8-bit Microprocessor - main
1x	Z80	4.000 MHz		8-bit Microprocessor - sound
1x	MSM5232	2.000 MHz		8 Channel Tone Generator - sound
1x	AY-3-8910	2.000 MHz		Programmable Sound Generator - sound

ROMs

QTY	Type	position	status

RAMs

QTY	Type	position

PLDs

QTY	Type	position	status

Others

ROMs: 17x 27128-27256
