EMU Infos
| dumper |
f205v
|
| date |
17/07/2012
|
| emulator |
MAME 0.169
|
| dev |
MetalliC
|
PCB Infos
| name |
wccf322e on Arcade Database
|
| description |
World Club Champion Football European Clubs 2004-2005 Ver.3.22 (Export) (CDV-10015P)
|
| year |
2005.11.21
|
| manufacturer |
Sega
|
Technical references
CPUs
| QTY
|
Type
|
clock
|
position
|
function
|
| 1x |
PIC16C621A |
|
(317-0419-EXP)(253-5508-0419E) |
8bit CMOS Microcontroller (internal ROM extracted)
|
ROMs
RAMs
PLDs
Others
Ver P
Notes
It's a NAOMI 2 Satellite Terminal disk.
Disk type: CD
Disk N°: CDV-10015P
Disk ID: BEG
Key: CEC7BA541A371AF2
Uses 837-14229 camera PCB
Files
-
Disk
-
