EMU Infos
| dumper |
f205v
|
| date |
17/07/2012
|
| emulator |
MAME 0.169
|
| dev |
MetalliC
|
PCB Infos
| name |
wccf212e on Arcade Database
|
| description |
World Club Champion Football Serie A 2002-2003 Ver.2.12 (Italy) (CDV-10002)
|
| year |
2004.12
|
| manufacturer |
Hitmaker - Sega
|
Technical references
CPUs
| QTY
|
Type
|
clock
|
position
|
function
|
| 1x |
PIC16C621A |
|
(317-0369-EXP)(253-5508-0369E) |
8bit CMOS Microcontroller (internal ROM extracted)
|
ROMs
RAMs
PLDs
Others
Update Disc (CD)
Notes
It's a NAOMI 2 Satellite Terminal disk.
Disk type: CD
Disk N°: CDV-10002
Disk ID: BGU
Key: 98CD1938C173619B
Uses 837-14229 camera PCB
