EMU Infos
| dumper |
f205v
|
| date |
17/07/2012
|
| emulator |
MAME 0.169
|
| dev |
MetalliC
|
PCB Infos
| name |
wccf234j on Arcade Database
|
| description |
World Club Champion Football Serie A 2002-2003 Ver.2.34 (Japan) (CDV-10008)
|
| year |
2004.12
|
| manufacturer |
Sega
|
Technical references
CPUs
| QTY
|
Type
|
clock
|
position
|
function
|
| 1x |
PIC16C621A |
|
(317-0369-JPN)(253-5508-0369J) |
8bit CMOS Microcontroller (internal ROM extracted)
|
ROMs
RAMs
PLDs
Others
Notes
It's a NAOMI 2 Satellite Terminal disk.
Disk type: DVD
Disk N°: CDV-10008
Disk ID: BGT
Key: 311619EAFD9E3720
Uses 837-14229 camera PCB
